Last updated: 26 September 2026
Quick Answer
Air Dry made to order fold down clotheslines from The Clothesline Store mount on a wall, in the ground or on concrete. Fix the brackets or legs level at about 1800mm, attach the frame, then thread and tension the lines.
Installing your Air Dry made to order clothesline is a simple DIY job with the right tools and instructions. This guide covers wall mounting, standard ground mount kits, the plated ground mount kit for concrete, the Low Line attachment and how to fold your frame up and down.
For every PDF manual and model-specific tip in one place, visit The Clothesline Store's Air Dry installation page.
Why Choose an Air Dry Made to Order Clothesline?
Air Dry clotheslines are Australian made from 100% Australian steel, with powder-coated frames, reinforced arms and brackets, and flexible mounting options. The made to order range is built to your chosen width, depth and colour, so it suits backyards, patios, courtyards and balconies of any size. Choose a Single, Twin Fold or Low Line, then mount it on a wall, in soil or over a concrete slab.
What's Included in Your Air Dry Kit?
Your kit includes the single or twin fold frame, folding arms, wall or leg brackets, wall plugs and fixings, and line cord with a threading diagram. A standard or plated ground mount kit and the Low Line accessory frame are included if you selected them.
Download the guide for your setup: the Wall Mount Installation Guide, the Ground Mount Booklet, the Twin Fold Wall Mount and GM Booklet or the Twin Fold Ground Mount Guide.
How to Install an Air Dry Clothesline Step by Step
1. Choose the location. Pick a spot where the frame can fully open and fold down without obstruction. Allow at least 500 to 600mm clearance in front, and set the frame at about 1800mm high, or shoulder height, for comfortable reach.
2. Fit the wall brackets. Use a spirit level to keep both brackets straight, mark the holes using the bracket as a template, drill and fit wall plugs for brick or rendered walls, then secure with the screws and washers supplied. On weatherboard, install structural timber support first. Never mount the clothesline on a fence.
3. Or set the ground legs. For a standard ground mount kit, dig two holes 550mm deep and about 200 to 250mm wide. Level the legs with a string line or spirit level, fill with concrete and let it cure for 24 hours before fitting the frame. Twin Fold models need extra bracket and arm assembly, shown in the Twin Fold GM booklet.
4. Attach the frame and arms. Slide the frame into place and secure the arms to the brackets with the bolts or pins provided. Check the arms pivot freely and the strut locks firmly when raised.
5. Thread and tension the lines. Follow the threading diagram for your model and feed the cord through the frame holes, keeping the tension even. Pull taut and tie off firmly. The lines can stretch slightly after the first few uses, so re-tensioning once they settle is normal.
How to Fold an Air Dry Clothesline Up and Down
To fold it down, remove all laundry and pegs, stand at the centre and gently lift the frame to release the strut. Then guide the arms down slowly until they sit flat against the wall or posts, and check the lines are still taut. To open it, lift the arms until the strut clicks into place and the frame is secure.
Installing the Plated Ground Mount Kit on Concrete
For concrete, pavers or anywhere you can't dig, use the Air Dry Plated Ground Mount Kit. Mark the bolt holes using the leg plates, drill with a masonry bit, secure the legs with the anchors or dynabolts supplied, then attach the frame. Download the Plated GM Kit instructions.
Air Dry Low Line Attachment
The Low Line attachment mounts beneath the main frame to add hanging space for socks, small garments and kids' clothes. It fits with the clips and extension arms supplied, works alongside the main frame, locks in place when you need it and folds away when you don't. View the Low Line instructions.
How to Maintain Your Air Dry Clothesline
Wipe down the arms, lines and brackets monthly, re-tension the cord if it sags, and lubricate the pivot points if they feel stiff. Avoid overloading the lines, and check bolts and anchors once a year. Using a clothesline cover will void the warranty on your Air Dry folding frame clothesline.
Prefer Professional Installation?
If you'd rather not install it yourself, see our clothesline installation and removal service for wall and ground mounted Air Dry clotheslines.
Related Guides from The Clothesline Store
Find out the best Australian made fold down clothesline, see the top wall mounted clotheslines for apartments, and read our guide to the best clothes horse in Australia.
Air Dry Made to Order Clothesline FAQs
How high should I mount an Air Dry fold down clothesline?
Around 1800mm above ground, or shoulder height, with at least 500 to 600mm clearance in front so the frame can open and fold freely.
What walls can I mount an Air Dry clothesline on?
Brick, rendered and masonry walls, using the fixings supplied. On weatherboard, install structural timber support first. Never mount it on a fence.
Can I install an Air Dry clothesline on concrete?
Yes. The Plated Ground Mount Kit bolts the legs straight onto concrete or pavers using masonry anchors, so no digging is needed.
What is the difference between Air Dry Made to Order and Ready Made?
Ready Made comes in set sizes and 3 colours for fast dispatch. Made to Order is built to your chosen width, depth from 0.6 to 1.5m and colour, with 11 colour options including Monument, Surfmist and Woodland Grey.
How long does an Air Dry Made to Order clothesline take?
Made to Order models are manufactured to order and typically dispatched within 3 to 7 business days.
Are Air Dry clotheslines Australian made?
Yes. Every Air Dry clothesline, Made to Order and Ready Made, is Australian made from 100% Australian steel.
Where can I buy an Air Dry Made to Order clothesline?
Online from The Clothesline Store, Australia's largest private clothesline stockist since 2003, with a 4.9 out of 5 star customer rating.
Final Thoughts
With careful measuring and the right guide for your model, installing an Air Dry made to order fold down clothesline is simple. Whether you're mounting to brick, setting legs in soil or bolting to concrete, you'll have a durable, space-saving clothesline built to your size and colour for years of daily use.
