Quick Answer
The Hills Long fold down clothesline from The Clothesline Store mounts to a wall only. Fix the brackets 3553mm apart with the supplied M8 × 70 masonry bolts, then assemble the frame and thread and tension the cord.
Setting up your Hills Long Fold Down Clothesline is easier than you might think, but taking the time to prepare properly will ensure it functions perfectly and lasts for years. With the right tools and a little planning, you'll have it up and ready in no time.
This guide will walk you through the installation process, whether you're mounting the clothesline on a brick, masonry, or concrete wall. We'll cover everything you need to do to get your clothesline securely fixed and ready to use.
One important thing to keep in mind: the Hills Long Fold Down Clothesline does not support installation with a ground mount kit or base plate kit, so it must be installed directly on a wall.
Before You Install the Hills Long Folding Frame Clothesline
Read the Hills Folding Clothesline Instructions prior to commencing the installation process of your clothes line.
Tools
Before you begin, make sure you have all the necessary tools and follow the step-by-step instructions supplied for the hills folding frame clothesline carefully to avoid any complications.
Important Information
The included Masonry Bolts are designed specifically for use on masonry, brick, or concrete walls, but if you're installing the folding frame clothesline yourself and mounting to another material, such as wood, be sure to consult your local hardware store for the appropriate fixings.
If you have chosen not to install the hills folding frame clothesline yourself and have engaged The Clothesline Store's professional installation service, our expert clothesline installer will have the correct fixtures and fittings with them for the hills folding frame clothesline.
Properly mounting the brackets and assembling the folding frame clothesline will ensure your clothesline is both stable and easy to operate, so you can start enjoying its benefits right away.
How to Install the Hills Long Folding Frame Clothesline
1.1 Select a Suitable Location
Select a location, outdoor space or indoors if applicable. Ensure there is sufficient clearance and space around the hills folding frame clothesline for air circulation, and that the folding frame clothesline is located away from obstacles i.e. trees.
Hills clotheslines recommend 500mm on the sides and 750mm from the front (Figure 1).
1.2 Marking the Hole Centres
Mark the hole centres. Using the brackets as templates, mark the hole centres.
The hole centres should be exactly 3553mm apart and Hills recommend the lower hole centres are in line with the users head height.
Use a spirit level to ensure the hole centres are level vertically and horizontally (Figure 2).
1.3 Adhere the Hills Clothesline Wall Brackets
If you are mounting to masonry, brick or concrete, drill 10mm holes at the marked points and secure into position using the M8 × 70.
Masonry Bolts are supplied with the folding frame clothesline (Figure 3).
If using alternative fixings, secure and adjust the brackets in an appropriate manner for your substrate.
How to Assemble the Hills Folding Frame Clothesline
2.1 Hills Folding Frame Clothesline Arm Caps
Slide the x4 Arm End Caps onto the end of each arm and strut, then secure the arms and struts into the brackets using the x 4 Chicago Bolts (Figure 4).
2.2 Hills Folding Frame Clothesline Assembly
Moving from right to left and keeping weight supported the whole time:
1 Insert x 1 Front Bar into the right arm
2 Slide the Joining Bar onto the Front Bar
3 Slide the remaining Front Bar into the Joining Bar
4 Carefully slot the assembled bars into the left arm corner.
The clothesline frame will now be fully assembled (Figure 5).
How to Attach the Clothes Line Cord
3.1 Threading the Hills Clotheslines Cord
Your hills folding frame clothesline comes with the Line Tensioner and Line pre-attached.
Thread the cord through the folding frame clothesline in alternating directions, keeping tension as you go (Figure 6).
3.2 How to Tie Off the Hills Clothes Line Cord
Follow the below steps to tie off (Figure 7).
Align the line tie off with the hole in the hills clothesline arm, and pull the line straight through the frame and line tie off.
Pull the line tight and down, then wedge it right to secure it into the gap at the base of the line tie off.
Thread the clothes line back and forth through the holes on the inner of the line tie off, so it finishes back on the inside of the arm.
Wedge it again, this time into the opposite side gap at the base of the line tie off, and snip off the excess.
Do not cut, until you are happy the clothes line cord is secure.
3.3 How to Tension Your Hills Folding Frame Clothesline
To tension the clothes line, rotate the line tension dial in a clockwise direction until the lines are taut (Figure 8).
The installation of your own quality long hills folding frame clothesline is now complete and you can start using your great quality hills folding frame clothesline!
You may need to adjust the clotheslines when you first hang your wet washing out to dry; this is the ideal time to check the cord tension.
How to Operate the Hills Long Folding Frame Clothesline
4.1 Raising the Long Folding Frame Clothesline
To raise, fold and lock the hills long clothesline, grip the frame in the middle and lift upwards until you hear both folding brackets 'click' (Figure 9).
4.2 How to Close the Long Folding Frame Clothesline
To lower and close the hills clothesline, grip the frame in the middle and raise slightly above your head until you hear both folding brackets 'click'! Then guide the frame into the folded closed position (Figure 10).
Hills Long Folding Frame Clothesline Specifications
Brand: Hills Clotheslines
Model: Long Fold Down
Colours: Monument, Surfmist
Suitable for: A family of 2–4 people
Number of lines: 6 lines, spaced 70mm apart
Length of line: 21.5m drying space for wet washing
Width: 3600mm
Depth: 680mm
Sheet size: King sheets
Assembly required: Yes
Fasteners / anchor bolts to wall: Masonry wall fixtures included
Ground mount kit: Not available
Can the width be reduced: Yes, you can reduce the width
Made in: China
Hills recommended weight capacity: 32kg
Hills manufacturer's warranty: Lifetime on frame / 12 months cord
Locations for installation: Outdoor walls, indoor garages, covered balcony
Professional clothesline installation available: Yes; clothesline installation is for external locations, outside of the house only.
Professional Clothesline Installation Service
If you're not keen on installing your new clothesline, The Clothesline Store makes clothesline installation incredibly easy, with our professional clothesline installation service that ensures your clothesline is set up effortlessly.
Whether you're choosing a fold down mounted, retractable, or a folding rotary clothesline, our expert installers are ready to help across the East Coast of Australia, including Sydney, Melbourne, Brisbane, Adelaide, and beyond, covering areas like Geelong, the Gold Coast, and Newcastle for all outdoor clothes line installations.
To book your clothesline installation service, simply select "Yes, Install My Clothesline" (or "Yes, Install and Remove Old Clothesline") when placing your order. If you have any questions about clothesline installation, please feel free to call and speak to one of our helpful team, who will be happy to assist you.
The Clothesline Store has various brands to choose from. Once you have chosen your clothesline, select the clothesline installation option, and you're on your way to having your new clothesline installed!
Want More Size Options? Consider Air Dry
If a standard size doesn't suit your wall, an Air Dry fold down clothesline is 100% Australian made from 100% Australian steel, in a wide range of ready made sizes or made to order for the perfect fit. It's The Clothesline Store's number one fold down pick.
Hills Clotheslines Full Product Range
Hills Premium Folding Rotary Clotheslines: 8 Line, 7 Line, 6 Line
Hills Everyday Folding Rotary Clotheslines: Everyday 37, Everyday 47
Hills Fixed Head Rotary Hoist Clotheslines: 7 Line, 6 Line
Hills Retractable Clotheslines: 7 Line Retracting, 5 Line Retracting
Hills Premium Fold Down Clotheslines: Single, Double, Long, Compact, Mini
Hills Everyday Fold Down Clotheslines: Everyday Double and Single
Hills Accessories: Soft Grip Pegs, Peg Bag
Related Guides from The Clothesline Store
Hills Fold Down Clothesline Sagging
Hills Folding Frame Clothesline Hard to Lift
How to Fix a Hills Folding Frame Clothesline
Hills Fold Down Clothesline: Repair or Replace?
Can I Install My Folding Frame Clothesline on a Fence?
FAQs: Hills Long Folding Frame Clothesline Installation
Can the Hills Long fold down clothesline be installed with a ground mount kit?
No. The Hills Long does not support a ground mount kit or base plate kit, so it must be installed directly on a wall.
How far apart are the Hills Long wall bracket hole centres?
The hole centres should be exactly 3553mm apart, with the lower hole centres in line with the user's head height.
How much clearance does the Hills Long need?
Hills recommend 500mm on the sides and 750mm from the front.
What fixings come with the Hills Long?
M8 × 70 masonry bolts are supplied for masonry, brick or concrete walls. For other materials, such as wood, consult your local hardware store for the right fixings.
Can I install the Hills Long on a weatherboard wall?
Only once structural timber support has been fitted to the wall first.
Can I install the Hills Long on a fence?
No. The Clothesline Store does not recommend mounting a fold down clothesline on a fence.
How do I tension the Hills Long clothesline cord?
Rotate the line tension dial clockwise until the lines are taut. Check the tension again when you first hang out wet washing.
What is the Hills Long weight capacity and warranty?
Hills recommend a 32kg weight capacity. The manufacturer's warranty is lifetime on the frame and 12 months on the cord.
