Quick Answer
Mark hole centres 2353mm apart at head height, drill 10mm holes, fix the brackets with the M8 masonry bolts, assemble the frame, then thread and tension the line. The Clothesline Store's Hills Single guide.
Installing a wall mounted Hills Single Folding Frame Clothesline, is a simple and easy process, but taking the time to prepare properly will ensure it functions smoothly and lasts for years.
This guide will walk you through the installation steps, whether you're mounting the clothes line on a brick, masonry, or concrete wall. Follow the instructions carefully to set up your Hills folding frame securely and get the most out of your new clothesline.
Installation Hills Folding Frame Clothesline - Single Model
In this guide, for the single hills folding frame clothesline we'll cover the key clothesline installation steps, from selecting the perfect location to securing the folding frame clothesline and attaching the line.
Tools
Before you begin, make sure you have all the necessary tools and follow the step-by-step instructions supplied for the hills folding frame clothesline carefully to avoid any complications.
Important Information Hills Ground Mount Kit or Plated Kit
The Single Hills Folding Frame Clothesline can be wall or ground mounted. If you choose to ground mount your single folding frame clothesline, you will need to purchase a Hills Folding Frame Ground Mount Kit, which is sold separately.
Please follow the instructions provided with the Post Kit for a ground mount installation or click here for more information on "How to install a Hills Ground Mount Kit"
Important Information Hills Wall Fixing
The included Masonry Bolts are designed specifically for use on masonry, brick, or concrete walls, but if you're installing the folding frame clothesline yourself and mounting to another material, such as wood or concrete walls, be sure to consult your local hardware store for the appropriate fixings.
If you have chosen not to install the hills folding frame clothesline yourself and have engaged The Clothesline Stores professional clotheslines installation service, our expert clothesline installer will have the correct fixtures and fittings with them for the hills folding frame clothesline.
Properly mounting the wall brackets and assembling the folding frame clothesline will ensure your clothes line is both stable and easy to operate, so you can start enjoying its benefits right away.
Installation of the Hills Single Folding Frame Clothesline
Read the Hills Folding Clothesline Instructions prior to commencing the installation process of your clothes line and lay all the items on the product list out neatly for the installation to commence.
1.1 Select a Suitable Location
Select an outdoor location. Ensure there is sufficient clearance and space around the hills folding frame clothesline.
Hills clotheslines recommend leaving a space of 500mm on the long sides and a space of 750mm from the front (Figure1).
1.2 Marking the Hole Centres
Mark the hole centres. Using the brackets as templates, mark the hole centres.
The hole centres should be exactly 2353mm apart and Hills recommend the lower hole centres are in line with the users head height.
Use a spirit level to ensure the hole centres are level vertically and horizontally (Figure 2).
1.3 Adhere the Hills Folding Frame Clothesline Wall Brackets.
If you are mounting to masonry, brick or concrete, drill 10mm holes at the marked points and secure into position using the M8 × 70 Masonry Bolts supplied with the folding frame clothesline (Figure 3).
If using alternative fixings, secure and adjust the brackets in an appropriate manor for your substrate.
Assembly of the Hills Folding Frame Clothesline
2.1 Hills Folding Frame Clothesline Arm Caps
Slide the x4 Arm End Caps onto the end of each arm and strut, then secure the arms and struts into to the brackets using the x4 Chicago Bolts (Figure 4).
2.2 Hills Folding Frame Clothesline Assembly
Moving from right to left and keeping weight supported the whole time:
1 Insert x 1 Front Bar into the right arm
2 Slide the Joining Bar onto the Front Bar
3 Slide the remaining Front Bar into the Joining Bar
4 Carefully slot the assembled bars into the left arm corner.
The clothesline frame will now be fully assembled (Figure 5).
Attaching the Line
3.1 Threading the Hills Clotheslines Cord
Your Hills Folding Frame Clothesline comes with the Line Tensioner and Line pre-attached.
Thread the line through the folding frame clothesline in alternating directions, keeping tension as you go (Figure 6).
3.2 How to Tie Off the Hills Clothesline Cord
Follow the below steps to tie off (Figure 7).
Align the line tie off with the hole in the hills clothesline arm, and pull the line straight through the frame and line tie off.
Pull the line tight and down, then wedge it right to secure it into the gap at the base of the line tie off.
Thread the clothes line back and forth through the holes on the inner of the line tie off, so it finishes back on the inside of the arm.
Wedge it again, this time into the opposite side gap at the base of the line tie off, and snip off the excess.
Do not cut, until you are happy the clothes line cord is secure.
3.3 How to Tension Your Hills Folding Frame Clothesline
To tension the line, rotate the line tension dial in a clockwise direction until the lines are taut (Figure 8).
Adjustments
You may need to adjust the lines when you first hang your wet washing out to dry. This is the ideal time to check the cord tension and adjust accordingly.
Operating Hills Folding Frame Clotheslines
4.1 Raising the Single Folding Frame Clothesline
To raise, fold and lock the hills clothesline, grip the frame in the middle and lift upwards until you hear both folding brackets 'click' (Figure 9).
4.2 How to Close the Single Folding Frame Clothesline
To lower and close, grip the frame in the middle and raise slightly above your head until you hear both folding brackets 'click! Then guide the frame into the folded closed position (Figure 10).
Congratulations, the install of your quality Hills Folding Frame Clothesline is now complete! You're all set to start enjoying the convenience of your new clothesline. We hope you have found this guide helpful and easy to understand.
Hills Single Folding Frame Clothesline Specification
Brand: Hills Clotheslines. Model: Single Fold Down Clothesline. Hills Single Clotheslines Colours: Monument, Surfmist. Hills Single Clotheslines Suitable For: Family of 2 – 4 People. Hills Single Clotheslines Number of Lines: 11 – Lines for Drying, Spaced 85 mm apart. Hills Single Clotheslines Length of Line: 26m Drying Space. Hills Single Clotheslines Width: 2400mm. Hills Single Clotheslines Depth: 1200mm. Hills Single Clotheslines Sheet Size: Queen Sheets. Hills Single Clotheslines Assembly Required: Yes. Hills Single Clotheslines Fasteners / Anchor Bolts to Wall: Yes 4 x Masonry Bolts. Can the Width of the Hills Single Clotheslines be Reduced: Yes, you can reduce the width. Hills Single Clotheslines Made in: China. Hills Recommended Weight Capacity: 34Kg. Hills Single Clotheslines Manufacturer's Warranty: Lifetime on Frame / 12 Months Cord. Hills Single Clotheslines Installation Location: Outdoor Walls, Indoor Garages, Covered Balcony. Hills Single Clotheslines Professional Clothesline Installation Available: Yes; clothesline installation is for external locations of the house. We are unable to install inside the home.
Professional Clothesline Installation Service
If you're not keen on installing your new clothesline at The Clothesline Store we make clothesline installation incredibly easy, with our professional clothesline installation service that ensures your clothesline is set up effortlessly.
Whether you're choosing a fold down mounted, retractable, or a folding rotary clothesline our expert installers are ready to help across the East Coast of Australia, including Sydney, Melbourne, Brisbane, Adelaide, and beyond, covering areas like Geelong, the Gold Coast, and Newcastle for all outdoor clothes line installations.
To book your clothesline installation service, simply select "Yes, Install My Clothesline" (or "Yes, Install and Remove Old Clothesline") when placing your order. If you have any questions, you would like answered, about clothesline installation please feel free to call and speak to one our helpful team who will be happy to assist you.
The Clothesline Store has various great quality brands to choose from, once you have chosen your clothesline, select the clothesline installation option, and you're on your way to having your clothes line installed!
Top Tip: Not all clothesline retailers offer clothesline installation services, if clothesline installation, clothesline removal or the cost of this service is important to you, make sure these services are available before purchasing your clothesline!
Want More Size Options? Consider Air Dry
If a standard size doesn't suit your wall, an Air Dry fold down clothesline is 100% Australian made from 100% Australian steel, in a wide range of ready made sizes or made to order for the perfect fit. It's The Clothesline Store's number one fold down pick.
Related Guides from The Clothesline Store
Find out how to measure for a new rotary clothesline, what's hot in the market like the top selling drying racks and why they are loved in Australia, and view the best Australian made fold down clothesline.
FAQs: Installing the Hills Single Folding Frame
How far apart are the Hills Single bracket holes?
The hole centres should be exactly 2353mm apart, with the lower hole centres in line with the user's head height.
How much clearance does the Hills Single need?
Hills recommends 500mm on the long sides and 750mm from the front.
What walls can I mount it on?
The supplied M8 masonry bolts suit masonry, brick and concrete walls. On weatherboard, install structural timber support first. Never mount a clothesline on a fence.
Can the Hills Single be ground mounted?
Yes, with a Hills Folding Frame Ground Mount Kit, sold separately.
How do I tension the line?
Rotate the line tension dial clockwise until the lines are taut, and recheck the tension when you first hang out wet washing.
