How Do I Install My New Air Dry Custom Made Fold Down Clothesline?
Installing your new Air Dry clothesline is a simple DIY job when you follow the right instructions, use the correct tools, and understand how the folding frame and components are designed to function.
Whether you’ve purchased a wall-mounted clothesline, a standard ground-mounted unit, or opted for a plated ground mount kit over concrete, this clothesline installation guide will walk you through each step for your new folding frame clothesline .
We’ll also cover specialty accessories like the Air Dry Low Line attachment, and provide folding clothesline folding instructions to help you get the most out of your Air Dry folding frame clothesline.
For full installation instructions, tips, and detailed PDF guides for every Air Dry clothesline model, visit The Clothesline Store’s official installation page. This page includes step-by-step guidance and downloadable manuals to make setup easy and stress-free—whether you're installing into brick, concrete, or studs.
TABLE OF CONTENTS
Why Choose an Air Dry Folding Frame Clothesline?
The Air Dry folding frame clothesline range is proudly Australian made, purpose-built for durability, functionality, and space efficiency.
Perfect for backyards, patios, courtyards, and balconies, these folding clotheslines feature high-grade, powder-coated steel frames, reinforced arms and brackets, and flexible mounting options.
Air Dry is a standout choice for homeowners who want longevity, reliable performance, and easy operation for daily drying needs.
Whether you choose a Single, Twin Fold, Low Line, or a custom size, you’ll enjoy a clothesline that's engineered to handle variable weather and loads.
With Air Dry’s adaptable systems, you can install your clothesline on walls, into soil, or over concrete slabs using a standard or plated ground mount kit.
What’s Included in Your Air Dry Clothesline Kit?
When you receive your new Air Dry clothesline, your kit will typically include:
-
The folding clothesline frame (single or twin fold)
-
Folding arms, wall or leg brackets
-
Wall plugs and fixing hardware
-
Line cord and threading diagram
-
Optional: Ground Mount Kit (standard or plated)
-
Optional: Low Line accessory frame (if selected)
📄 Be sure to read the correct clothesline installation instruction sheet based on your setup:
Step-by-Step Air Dry Clothesline Installation
Choose the Right Location
Select a space that allows your frame to fully extend and fold down without obstruction. Measure the width of your line and allow at least 500–600mm clearance in front.
The frame should sit at roughly 1800mm above ground level, or shoulder height, for comfortable reach.
Mark and Install Wall Brackets or Ground Legs
If wall mounting:
-
Use a spirit level to ensure both brackets are straight.
-
Mark drill holes using the bracket as a template.
-
Drill and install wall plugs if needed (for brick or rendered surfaces).
-
Secure brackets with screws and washers.
If using a standard ground mount kit:
-
Dig two holes 550mm deep and approx. 200–250mm wide.
-
Position and level the legs using a string line or level.
-
Fill with concrete and allow to cure for 24 hours before attaching the frame.
For Twin Fold models, follow the extra bracket and frame arm assembly shown in the clothesline installation Twin Fold GM booklet.
Attach the Folding Frame and Arms
Once the brackets or legs are installed:
-
Slide the clothesline frame into place.
-
Use the bolts or pins provided to secure the arms to the brackets.
-
Ensure arms pivot freely and the strut locks firmly when raised.
Thread and Tension All the Lines
Use the line threading diagram included with your model. Feed the polycord through the frame holes, maintaining even line tension throughout.
Tip: Once threaded, pull taut and tie off firmly. The lines may stretch slightly after the first few uses, so it’s normal to re-tension them once they settle.
Folding Clothesline Folding Instructions
To fold down your Air Dry frame:
Remove any laundry and pegs.
Stand at the centre and gently lift the frame to release the strut.
Guide the arms down slowly until they lie flat against the wall or upright posts.
Double-check that all the lines remain taut.
To fold back up, lift the arms until the strut clicks into place and the frame is securely upright.
Installing the Plated Ground Mount Kit (Concrete Surfaces)
If you are installing over concrete, you’ll need the Air Dry Plated Ground Mount Kit, which includes base plates with pre-drilled holes for bolt-down installation.
Key Steps:
-
Position and mark the bolt holes using the leg plates.
-
Drill into concrete using a masonry drill bit.
-
Use the included anchors or dynabolts to secure the legs.
-
Attach the clothesline frame once plates are fixed.
Download the Plated GM Kit Instructions
This solution is ideal for patios, balconies, or any outdoor paved area where digging isn’t possible.
Air Dry Low Line Attachment Overview
The Air Dry Low Line attachment is a bonus drying rack that mounts beneath the main frame, offering extra hanging space for socks, small garments, and kids' clothes.
-
Installed using clips and extension arms included in the kit
-
Operates in tandem with the main folding frame
-
Can be locked into place when extra drying space is needed
-
Easily detached or folded down when not in use
View the Low Line Attachment Instructions
This is an excellent solution for households looking to maximise line space without using more backyard area.
Maintenance & Long-Term Performance
To keep your Air Dry folding frame clothesline in top condition:
-
Wipe down the arms, lines, and brackets monthly
-
Retension polycord if it sags over time
-
Lubricate pivot points if they feel stiff
-
Avoid overloading the line weight
-
Check bolts and anchors annually for stability
Top Tip: The use of clothesline covers will void the warranty of your new Air Dry folding frame clothesline.
Professional Clothesline Installation Services
Want a fast, hands-off experience? The Clothesline Store offers expert clothesline installation services for all Air Dry folding clotheslines—wall or ground mounted.
Our professional team will:
-
Install your clothesline
-
Assemble your wall brackets or leg kits
-
Accurately tension and test all the lines
-
Ensure proper folding operation
-
Clean up all packaging
Click here to book an installation
Final Thoughts
Installing your Air Dry fold down clothesline is easy when you follow the correct instructions, measure carefully, and prepare your space.
Whether you're mounting to brick, soil, or concrete, Air Dry provides all the components you need for a long-lasting, space-efficient drying solution.
With optional features like the Low Line attachment and plated ground mount kits, you can customise your install to fit your lifestyle.
And with every Air Dry unit Australian made, you’re supporting local manufacturing while enjoying a durable, reliable clothesline for years to come.
Ready to install or upgrade your Air Dry clothesline?
Air Dry Clotheslines FAQ's
What is the difference between Air Dry Custom Made and Ready Made clotheslines?
Air Dry Custom Made clotheslines offer a wider range of sizes, colours, and configurations to suit your specific space and drying needs. Unlike the Ready Made range—which includes pre-selected sizes and limited colours for fast dispatch—Custom Made models are built to order. This allows you to choose the perfect frame width, depth, and colour finish to match your home.
Can I customise the width and depth of an Air Dry clothesline?
Yes, with Air Dry’s Custom Made service, you can select a specific width (up to 3.3 metres) and depth to maximise your drying space. This flexibility is perfect for narrow side yards, compact patios, or large family homes that need extra line space. Simply choose your size when ordering through The Clothesline Store.
How long does it take to receive a custom made Air Dry clothesline?
Custom Made Air Dry clotheslines are manufactured to order and typically dispatched within 3–7 business days. While they take a little longer than Ready Made models, the tailored fit and finish make them well worth the wait—especially if you're working with tight dimensions or want a colour to match your home’s exterior.
What colour options are available for Air Dry Custom Made models?
The Air Dry Custom range includes a variety of Colorbond-inspired finishes such as Monument, Surfmist, Paperbark, Woodland Grey, and Classic Cream. This allows you to coordinate your new clothesline with fences, sheds, or walls for a seamless outdoor look.
Are Air Dry Custom Made clotheslines also Australian made?
Yes! Every Air Dry Custom Made clothesline is proudly Australian made using premium-grade materials. Supporting local manufacturing means you're investing in durability, weather resistance, and quality workmanship backed by reliable customer service and fast support from The Clothesline Store.
